PowerBall® 500 Amp Robotic Torch
PowerBall® High Performance Robotic Torches are engineered to provide maximum conductivity with increased consumable life. The innovative torch design provides a higher amperage output than traditional air-cooled MIG welding torches, resulting in an energy efficient torch that can take on demanding welding applications. Higher conductivity and energy efficiency also means less heat build-up, increased consumable life and reduced spatter build-up on the contact tip and nozzle. Proudly Made in USA.
- Description
- Product Literature
- Shipping Information
Description
PowerBall® High Performance Robotic Torches are engineered to provide maximum conductivity with increased consumable life. The innovative torch design provides a higher amperage output than traditional air-cooled MIG welding torches, resulting in an energy efficient torch that can take on demanding welding applications. Higher conductivity and energy efficiency also means less heat build-up, increased consumable life and reduced spatter build-up on the contact tip and nozzle. Proudly Made in USA.
- Modular uni-cable design provides up to 2X cable service life
- Available in 220° or 360° rotation and may be converted without changing TCP or torch housing
- All-copper current path with ultrasonically welded copper cable connections provides optimum current transfer
- Long-life contact tips, torch liners and nozzles reduce consumable costs
- 100% duty cycle at up to 500 A — excels in high volume production!
- Thru-arm torch mounts available for most popular arc welding robot models (see list below)
- Click here to see the full line of PowerBall® Consumables
PowerBall® Robotic Torches can currently be integrated with the following robot models:
Contact customer support if you have another robot model not listed below.
| FANUC® Fanuc 100iD Fanuc 100iD/8L Fanuc 100iD/10L Fanuc 120iD Fanuc 120iD/12L Fanuc 100iC (M-10iA) Fanuc 100iC/12 Fanuc 100iC/12S Fanuc 100iC/6L Fanuc 100iC/7L Fanuc 100iC/8L Fanuc 120iC Fanuc 120iC/10L Fanuc 120iC/12L |
KUKA® KR 6 R1840-2 KR 8 R1420-2 KR 8 R1640-2 KR 8 R2100-2YASKAWA® AR1440 AR1730 AR2010 AR3120KAWASAKI® BA006N |
ORDERING & CUSTOMER SERVICE:
Our sales and customer service representatives are available Monday-Friday, 8:00AM-5:00PM (EST) at our main office by calling 517-782-8040. Any orders placed after 3:00PM for same day shipping will be charged a $50.00 expedite fee. We can also be reached by fax 24 hours a day, seven days a week at 517-782-8039. When ordering, please state your company’s “bill to” and “ship to” address, purchase order number, part number, quantity, item description, and any special shipping instructions. All purchases will be shipped UPS ground unless otherwise specified. Items too large for UPS, will be shipped by commercial carrier.
INTERNATIONAL ORDERS OUTSIDE NORTH AMERICA:
International orders outside of North America will be shipped by our global distribution partners. ELCo Enterprises has distributors located worldwide in Europe (Wire Wizard Europe), Asia, Australia, India and elsewhere.
RETURNS:
All returns must be in new condition and authorized by ELCo by use of a Returned Merchandise Authorization
Number (RMA) within 30 days of the purchase date. Returns are subject to a 20% restocking fee.
$75 minimum order.
NOTE: Purchases cannot be delivered to post office boxes.
